Possible to take wheels from one vehicle to put on another?

I wanted to know if it is possible to take wheels from the Ibishu Pigeon STI-G and put them on the Gavril Pickups and if so how? any help is greatly appreciated!!!



Yes of course there is always a way. and here's how(I don't have that mod installed but I've done it with Alder Draggers before.)
A mod would be recommended because it will add to most 5-Lug wheels. So make a mode folder like
yourmodname\vehicles\common

You will need any tire resources transferred to this common folder(with the drag tires, everything was already there)
Then make sure you change the following(only if you remove the mod, but it will might overwrite the mod)
EX: "wheel_4_lug_15x7_R" The reason for this was for a Drag Miramar which is 4-Lug

If it is usual wheel then it should be basically like:

Code:

"wheel_4_lug_15x7_R": {
    "information":{
        "authors":"joelebauer01",
        "name":"Alder Dragger 15x7 Rear Wheels",
        "value":270,
    }
    "slotType" : "wheel_R_4",
    "slots": [
        ["type", "default", "description"]
        ["tire_R_15x7_alt","tire_R_185_75_15_standard", "Rear Tires"],
    ],
    "flexbodies": [
        ["mesh", "[group]:", "nonFlexMaterials"],
        //wheels
        ["wheel_09a_15x7", ["wheel_RR","wheelhub_RR"], [], {"pos":{"x":-0.52, "y":0.0, "z":0.0}, "rot":{"x":0, "y":0, "z":180}, "scale":{"x":1, "y":1, "z":1}}],
        ["wheel_09a_15x7", ["wheel_RL","wheelhub_RL"], [], {"pos":{"x": 0.52, "y":0.0, "z":0.0}, "rot":{"x":0, "y":0, "z":0}, "scale":{"x":1, "y":1, "z":1}}],
    ],
    "nodes": [
        ["id", "posX", "posY", "posZ"],
        //rear wheel nodes
        {"frictionCoef":0.5},
        {"nodeMaterial":"|NM_METAL"},
        {"chemEnergy":200,"burnRate":0.5,"flashPoint":300,"smokePoint":200,"selfIgnition":0,"specHeat":1},
        {"selfCollision":true}
        {"collision":true}
        {"nodeWeight":5.0},
        {"group":"wheelhub_RR"},
        ["rw1r", -0.33, 0.0, 0.0],
        {"group":"wheelhub_RL"},
        ["rw1l", 0.33, 0.0, 0.0],
        {"collision":true}
        {"group":"wheelhub_RR"},
        ["rw1rr", -0.60, 0.0, 0.0],
        {"group":"wheelhub_RL"},
        ["rw1ll", 0.60, 0.0, 0.0],
        {"chemEnergy":false,"burnRate":false,"flashPoint":false,"smokePoint":false,"selfIgnition":false,"specHeat":false},
        {"group":""},
    ],
    "beams": [
          ["id1:", "id2:"],
          {"beamPrecompression":1, "beamType":"|NORMAL", "beamLongBound":1.0, "beamShortBound":1.0},
          //rear wheels
          {"breakGroupType":0},
          {"beamSpring":801000,"beamDamp":6},
          {"beamDeform":29250,"beamStrength":434000},
          ["rw1r","rw1rr"],
          ["rw1l","rw1ll"],
          {"breakGroup":""},
          {"beamPrecompression":1, "beamType":"|NORMAL", "beamLongBound":1.0, "beamShortBound":1.0},
    ],
    "pressureWheels": [
        ["name","hubGroup","group","node1:","node2:","nodeS","nodeArm:","wheelDir"],
        {"disableMeshBreaking":true,"disableHubMeshBreaking":false,"enableHubcaps":false,"hasTire":false},

        //general settings
        {"hubRadius":0.20},
        {"wheelOffset":-0.055},
        {"hubWidth":0.205},
        {"numRays":16},

        //hub options
        {"hubTreadBeamSpring":1101000, "hubTreadBeamDamp":10},
        {"hubPeripheryBeamSpring":1101000, "hubPeripheryBeamDamp":10},
        {"hubSideBeamSpring":1651000, "hubSideBeamDamp":10},
        {"hubNodeWeight":0.47},
        {"hubNodeMaterial":"|NM_METAL"},
        {"hubFrictionCoef":0.5},
        {"hubBeamDeform":68600, "hubBeamStrength":76000},
    ],
}

Then all you need to change is what kind of slot it can go on "slotType" : "wheel_R_4",

This might not work, and if it doesn't work I'll download the mod, and do it for you. It isn't that hard for me.



FWIW I suspect that you'll run into other problems once you get the wheels mounted. They are much larger than those which are normally mounted on the Gavril pickups. See my post on that subject here: http://www.beamng.com/threads/ibishu-pigeon-sti-g.25659/page-3#post-390135

Clearing the wheel wells is going to be an issue.



Thank you very much for the reply, very appreciated, I just love those wheels they remind me of like duratracs or something and the are very detailed, at the right scale would be perfect for the pickup!



Thanks so much! I'll see what can be done, new to this stuff haha



I don't have gimp, or blender installed currently, and my internet is bad so it might take a while.



Well... this is my first time actually having to add files from another mod so I don't know how to do this well.
